RHEEM 86VP SERIES

PRODUCTS

CLASSIC ELECTRIC STORAGE WATER HEATER HORIZONTAL MODEL —86VP SERIES

Features
  • Solid heater tank, long proven in millions of installations worldwide
  • CFC free polyurethane foam with epoxy coated jacket for superior heat retention to reduce heating time and enhance energy savings
  • Self-sacrificing magnesium anode rod to counter aggressive water to prolong lifespan of water heater
  • High performance Incoloy 800 immersion type heating element to provide fast heating, protect heating element from rust, and withstand high temperature
  • Wall hung installation mounted bracket provided
  • Thermal cut out to avoid overheating and prevent scalding
  • Temperature and pressure relief valve with built in check valve to prevent excessive temperature and pressure in inner tank
Model Tank
Capacity
Stainless Steel
Element
Operating Weight
(kg)
Heater Dimensions
(mm)
Shipping Weight
(kg)
Shipping Dimension
(mm)
Current Draw
(amps)
Over Current Protection
(amps)
Approx.* Heat up Time to 60°C
(mins)
USG Litres Voltage Kw Diameter Height Length Breadth Height
86VP6S 6 25 240 3.0 42 377 460 17 409 409 548 12.5 15 20
86VP10S 10 42 65 461 487 23 493 493 575 34
86VP15S 15 50 74 461 554 24 493 493 642 40
86VP20S 20 75 105 461 764 30 493 493 851 60
86VP30S 30 100 136 461 973 36 493 493 1060 80
*Heat up time is calculated based on a 3kw, incoming temperature of 25°C. All pip size for inlet and outlet —3/4" BSP. All single phase.
