CLASSIC ELECTRIC STORAGE WATER HEATER HORIZONTAL MODEL —86H SERIES
Features
- Exclusive Rheemglas enamel tank protection against corrosion
- UL approved temperature and pressure relief valve
- Adjustable thermostat with over temperature protection
- Incoloy 840 heating element to prolong lifespan
- Sacrificial magnesium anode rod to protect inner tank from corrosion
- High density polyurethane insulation foam between inner tank and epoxy coated steel jacket
• All Dimensions in mm
* Please specify Left or Right connection when ordering. Above diagram shows Left connection heater.
| Model |
Tank
Capacity
(Litres)
|
Mounting |
Dimensions (mm) |
Approx*.
Heat up Time
to 60°C (mins) |
Preset Temperature
(°C) |
Heating Element
Input (kW)
(240V)
|
Shipping Weight
(kg)
|
Operating Weight
(kg)
|
| A |
B |
C |
D |
E |
F |
G |
| 86H-25 |
25 |
Horizontal |
460 |
320 |
70 |
377 |
396 |
150 |
426 |
20 |
60 |
3 |
17 |
42 |
| 86H-40 |
40 |
664 |
340 |
162 |
377 |
396 |
150 |
426 |
32 |
22 |
62 |
| 86H-55 |
55 |
868 |
477 |
195.5 |
377 |
396 |
150 |
426 |
44 |
25 |
80 |
| 86H-75 |
75 |
1140 |
812 |
164 |
377 |
396 |
150 |
426 |
60 |
31 |
106 |
| 86H-100 |
100 |
973 |
643 |
165 |
461 |
480 |
240 |
510 |
80 |
36 |
146 |
